industrial sesame seed peeling machine sesame seed hulling machine

Ask Lasest Price
Brand Name :	JIANGCHEN
Certification :	ISO9001
Model Number :	QD-TP200
Price :	USD2000-30000
Delivery Time :	in 10 days after received down or full payment
Payment Terms :	100% payment T/T inadvance, or can pay via PAYPAL,WEST UNION
Supply Ability :	100 sets per month

Add to Cart

Product Details
Company Profile

industrial sesame seed peeling machine sesame seed hulling machine

sesame peeling machine specifications:

Size:1400*1000*1900mm

weight:400kg

capacity: 200-400kg/h

power:6 kw

voltage:380v/50hz

material: carbon steel/stainless steel

Sesame Peeling Machine introduce:

This machine can be applied to sesame soaking,sesame skin removing,sesame skin and kenel’s separating. Combining all the process above together.

sesame peeling machine Working Principle

1.Soaking

The special stirer,which is driven by decelerator,puts forward the peripheral sesame seed and the center sesame will continulously move downwards,in this way, the sesame will move up and down,later the sesame soak in water totally.

2. Skin Removing

The stirrer driven by decelerator makes the soaked sesame rotating rapidly up and down.The hull will removed from the kernel by the friction between sesame and the rotating from the stirrer.

3.Skin and Kernel’s Separating

The hull and kernel are pushed continulously by the stirrer driven by decelerator to move in radial and axile direction. The hull is discharged through the holes on the plate, while the kernel is sustained by the plate with holes, and thus they are separated from each other

sesame peeling machine pictures；

industrial sesame seed peeling machine sesame seed hulling machine
